Parameters Measurable Material Testing Lab Equipments Specimen Information Input

Name: Parameters Measurable Material Testing Lab Equipments Specimen Information Input
Brand: wangtebei
Price: 1 USD

China Parameters Measurable Material Testing Lab Equipments Specimen Information Input factory

Brand Name : wangtebei

Model Number : WAW-300/600/1000/2000

Place of Origin : China

MOQ : 1 set

Price : negotiation

Payment Terms : T/T, L/C

Supply Ability : 50 sets per month

Delivery Time : 15 working days

Packaging Details : export package

Dim of control cabinet : 1100x700x950mm

Capacity(kN) : 300-3000KN

Round specimen range(mm) : Dia. 10-32

Compression platen(mm) : 200x200

structure : 4 columns 2 lead screws

Measuring force range : 2%-100%FS

Contact Now

Product Description

electro-hydraulic servo type universal testing machine using the hydraulic power source is driven, electro-hydraulic servo control and computer data acquisition and processing.It is a closed-loop control and automatic detection precision materials testing equipment,It is composed of four parts: test host, oil source (hydraulic power source), measurement and control system and test apparatus.The maximum test force is 2000kN, test machine accuracy level is better than 1 level.

Specification

Maximum test force	2000KN
Oil tank size(mm)	800mm600mm1600mm
Beam lifting speed( mm/min)	350mm/min
Maximum tensile spacing(mm)	800mm
Piston stroke(mm)	250mm
Upper and lower Pressure plate dimensions(mm)	240mm*240mm
Maximum spacing of compression surfaces(mm)	650mm
Displacement measuring resolution(mm)	0.001mm
The relative error of the test force	±1%
Effective measuring range	1%-100%F.S

Our Service

1. Professional and passion sales team 24 hours at your service.

2. Participating in the various exhibitions help you to know us more completely .

3. Sample could be sent in 1-3days.

4. OME of customized products/logo/brand/packing is accepted.

5. Small quantity accepted and quick delivery.

6. Our own product Development Team will regularly update new products.

7. Product diversification for you choice.
